DESCRIPTION

NEVER THE SAME AGAIN

Just like triathlon is a competition of multiple disciplines, Ordu is an elegant blend of aerodynamics, weight, handling and ergonomics. Once you have experienced Ordu’s multiple strengths, it is impossible to feel confident with a lesser machine. For those who aim to be the fastest, most efficient and decorated athletes, Ordu is the future. You and triathlon will never be the same again.

PERFECT BALANCE

Historically, considering only the three design factors of aerodynamics, stiffness and weight rarely yields dramatic improvement. Big gains in one of the three areas always compromise one or both of the others.

The key to building the best triathlon bike is finding the balance of these targets, and identifying additional performance factors that allow the rider to increase efficiency.

AERODYNAMICS

It required more than 2,500 hours of calculations… Analyzing the frame, fork and cockpit assembly and identifying areas to refine and reduce aerodynamic resistance.

WEIGHT

We analyzed the areas where large amounts of material were being used for rigidity.

ERGONOMICS

Ordu is designed to fit the widest possible range of riders. The ergonomics are easily modified over a huge range with just a few adjustment points, easily adaptable for any rider or race regulations. It doesn’t matter if you’re very flexible or not…Ordu will meet your needs.

The new Ordu is for the serious triathlete looking to upgrade an existing bike to something faster and more ergonomic with more integration and lower weight.

Ordu is also the choice of elite or professional road racers who need a UCI-legal time trial bike. Ordu is the racing platform of many Orbea-sponsored teams, and of course our Orbea Pro Triathletes, Lotto Dstny, Fundacion Euskadi and Ceratizit - WNT Team riders.

SPECIFICATIONS

• FRAME: Orbea Ordu carbon OMX Disc, monocoque construction, HS 1" - 1 1/8" mini tapered, BB 386mm, powermeter compatible, Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing.
• FORK: Orbea Ordu OMX ICR fork 2021, full carbon, 1" head tube, Thru axle 12x100m, thread M12x2P1, Speed release compatible dropout. UCI Legal.
• HEADSET: FSA 1-1/8"-1" Integrated Aluminium Cup
• CRANKSET: Shimano Ultegra R8100 36x52t
• SHIFTERS: Shimano R9180
• CASSETTE: Shimano Ultegra R8100 11-30t 12-Speed
• REAR DERAILLEUR: Shimano Ultegra Di2 R8150
• FRONT DERAILLEUR: Shimano Ultegra Di2 R8150
• CHAIN: Shimano M8100
• HANDLEBAR: Orbea Ordu OMX
• EXTENSION: Vision Metron TFA Carbon Aero Clip-on JS-Bend (Non UCI compliant)
• BRAKES: Shimano R9270 Hydraulic Disc
• ROTORS: 140mm Front /140mm Rear
• WHEELS: Oquo Road Performance RP57LTD
• TYRES: Vittoria Corsa N.Ext G2.0 Foldable 700x28c
• FRONT WHEEL AXLE: Orbea Thru Axle 12x100mm M12x2 P1 Lite
• REAR WHEEL AXLE: Orbea Thru Axle 12x142mm M12x2 P1 Lite
• SEATPOST: Orbea Ordu OMX, w/Micro tilt adjustment
• SADDLE: Fizik Transiro LD R5 size 135mm
• HANDLEBAR TAPE: Orbea Eva
• HYDRATION: OC Aero Bottle RA10 (550ml) + Carbon Cage Kit RA10
• STORAGE: OC Aero Toolbox TB01PP

SIZE GUIDE

*Estimated Measurements
