DESCRIPTION

NEVER THE SAME AGAIN

Just like triathlon is a competition of multiple disciplines, Ordu is an elegant blend of aerodynamics, weight, handling and ergonomics. Once you have experienced Ordu’s multiple strengths, it is impossible to feel confident with a lesser machine. For those who aim to be the fastest, most efficient and decorated athletes, Ordu is the future. You and triathlon will never be the same again.

PERFECT BALANCE

Historically, considering only the three design factors of aerodynamics, stiffness and weight rarely yields dramatic improvement. Big gains in one of the three areas always compromise one or both of the others.

The key to building the best triathlon bike is finding the balance of these targets, and identifying additional performance factors that allow the rider to increase efficiency.

AERODYNAMICS

It required more than 2,500 hours of calculations… Analyzing the frame, fork and cockpit assembly and identifying areas to refine and reduce aerodynamic resistance.

WEIGHT

We analyzed the areas where large amounts of material were being used for rigidity.

ERGONOMICS

Ordu is designed to fit the widest possible range of riders. The ergonomics are easily modified over a huge range with just a few adjustment points, easily adaptable for any rider or race regulations. It doesn’t matter if you’re very flexible or not…Ordu will meet your needs.

The new Ordu is for the serious triathlete looking to upgrade an existing bike to something faster and more ergonomic with more integration and lower weight.

Ordu is also the choice of elite or professional road racers who need a UCI-legal time trial bike. Ordu is the racing platform of many Orbea-sponsored teams, and of course our Orbea Pro Triathletes, Lotto Dstny, Fundacion Euskadi and Ceratizit - WNT Team riders.

SPECIFICATIONS

FRAME

Orbea Ordu carbon OMX Disc, monocoque construction, HS 1" - 1 1/8" mini tapered, BB 386mm, powermeter compatible, Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing.

FORK

Orbea Ordu OMX ICR fork 2021, full carbon, 1" head tube, Thru axle 12x100m, thread M12x2P1, Speed release compatible dropout. UCI Legal.

HEADSET

FSA 1-1/8"-1" Integrated Aluminium Cup

CRANKSET

Shimano 105 R7100 36x52t

SHIFTERS

Shimano R9180

CASSETTE

Shimano 105 R7100 11-34t 12-Speed

REAR DERAILLEUR

Shimano 105 Di2 R7150

FRONT DERAILLEUR

Shimano 105 Di2 R7150

CHAIN

Shimano M6100

HANDLEBAR

Orbea Ordu OMX

EXTENSION

Vision Metron TFA Carbon Aero Clip-on JS-Bend (Non UCI compliant)

BRAKES

Shimano R9270 Hydraulic Disc

ROTORS

140mm Front /140mm Rear

WHEELS

Oquo Road Performance RP45TEAM

TYRES

Vittoria Corsa N.Ext G2.0 Foldable 700x28c

FRONT WHEEL AXLE

Orbea Thru Axle 12x100mm M12x2 P1 Lite

REAR WHEEL AXLE

Orbea Thru Axle 12x142mm M12x2 P1 Lite

SEATPOST

Orbea Ordu OMX, w/Micro tilt adjustment

SADDLE

Fizik Transiro LD R5 size 135mm

HANDLEBAR TAPE

Orbea Eva

HYDRATION

OC Aero Bottle RA10 (550ml) + Carbon Cage Kit RA10

STORAGE

OC Aero Toolbox TB01PP

SIZE GUIDE

Size	Height (cm)
XS	170
S/M	170-180
M/L	175-185
XL	185

*Estimated Measurements
