DESCRIPTION

Orca isn’t just light. It is 6.7kg of climbing technology designed to change how you reach the top.

The feeling of a bike this light and efficient is unbeatable, and this instant acceleration, vibration absorption and responsive handling come from a frame which knows where it needs to be light and where it needs to be stiff. Welcome the ultimate climbing machine!

Dominate the Climbs

Achieving Orca´s light weight required many marginal gains, focusing on the details and using the best materials across the range. Considering the bike as a package means working with component and wheel designers right from the start to optimize stiffness and weight.

Weight

Pure Light

The most efficient Aero bikes can never be truly lightweight and in the same way the lightest bikes can never be super aero. Trying to make a tool do many different jobs often results in something that isn’t good at anything.

When the gradient of the climb means that your speed drops below around 15kmph, gravity starts to affect your ride more than air resistance. The gradient at which this occurs depends on each rider. Here a lightweight bike offers clear advantages.

Rigid in All The Right Places

But having the lightest bike is worth nothing if it isn’t stiff and efficient. When we designed Orca, we started with a target rigidity to ensure that even the strongest climbers could be sure of efficient power transmission. Then we designed Orca to be as light as possible without compromising that number.

The Feel of the Freedom

There is indeed just something special about the feel of a lightweight bike. We love the instant acceleration when you stamp on the pedals and the responsive, agile handling as you carve through the turns.

No Trade-Offs

Our clever frame design means that stiff doesn't have to be uncomfortable. Rounder frame sections help reduce vibrations, saving energy on longer rides and offering you an advantage on that final climb. Wider clearance allows for tires of up to 32mm—maximizing traction and compliance.

Performance Design

Orca is built on our understanding of performance and design, reflecting our belief that bikes should look great and ride better. Orca’s minimal, timeless lines give it its distinctive style and cover some very modern technology.

REGISTER FOR YOUR WARRANTY AND BENEFITS

LIFETIME WARRANTY

We offer a lifetime warranty on your bike frame once the legal warranty period has expired.

ACCIDENT POLICY

If your bike cracks or breaks due to external factors, we’ll provide you with a discount for a similar new frame.

EXCLUSIVE BENEFITS

You get access to exclusive contests and prizes and have priority access to products and promotions.

SPECIFICATIONS

FRAME

Orbea Orca carbon OMX Disc, monocoque construction, HS 1,5", BB 386mm, power meter compatible, Rear Thru-Axle 12x142mm, thread M12x2 P1, internal cable routing, EC/DC compatible, OMX specific seat tube.

FORK

Orbea Orca OMX ICR fork 2020, full carbon, 1-1/8" - 1,5" tapered head tube compatible, Thru-axle 12x100mm, thread M12x2 P1, Speed release compatible dropout.

WHEELS

Vision 40 SC Disc Carbon TLR CL

AXLES FRONT

Orbea Thru Axle 12x100mm M12x2 P1 Lite

REAR

Orbea Thru Axle 12x142mm M12x2 P1 Lite

TIRES

Vittoria Corsa Competition G2.0 TLR 700x25c

CRANKSET

SRAM RED 1 AXS Power Meter Dub 35x48T

SHIFTERS

SRAM RED eTap AXS

FRONT DERAILLEUR

SRAM RED eTap

REAR DERAILLEUR

SRAM RED eTap

CASSETTE

SRAM XG-1290 10-28T 12-Speed

CHAIN

SRAM RED 12-Speed

BRAKES

SRAM RED eTap AXS

HANDLEBARS

OC RP10 Road Performance Carbon, Reach 80, Drop 125, w/Di2 hole

GRIPS

Lizard Skins DSP 2.5mm

STEM

OC RP10 Road Performance ICR, -8°, IFC02 Computer mount interface

HEADSET

Acros Alloy 1-1/2" Internal Cable Routing, Stainless Steel Bearing

SEATPOST

Orbea Orca OMX, SB0/25, w/Micro tilt adjustment

SADDLE

Selle Italia SLR Boost SuperFlow L Carbon Keramic Rail Ø7 x 9 mm

SIZE GUIDE

Size	Height (cm)
47	155-160
49	160-166
51	167-172
53	173-179
55	180-185
57	186-191
60	192-207
